PARTS LIST
POWER AMP
PRINTED CIRCUIT BOARD ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
4 014171 SCREW M 4-40X3/8" PHP BLX (AT Q8,14-17)
14 033051 SCREW M 6-32X1/2" PHPS ZI (AT Q18,20-23,25)
(AND STANDOFFS)
4 037568 SCREW M 6-32X3/4" PHP ZI (AT Q19,24)
16 025805 SLEEVE INSULATING 3/16" (AT Q18-25)
4 036235 SPACER AL #6X1/4X1/4" (AT Q19,24)
2 025804 STANDOFF 6-32X1/2 RND AL (HEATSINK MOUNT)
1 029779 SWITCH THERMAL NC (OPEN 248
o
F) TS1 (CIRCUIT BREAKER)
1 032906 SWITCH THERMAL NO(CLOSE 194
o
F) TS2 (FAN HI/LO SPEED)
20 025802 TAB MALE .250X.032 PCB MT CP1-25
1 026411 THERMISTOR 2.5 ohm 8 AMP TH1
4 022376 WASHER FLAT 6X3/8 NI (AT Q19,24)
4 017746 WASHER SHOULDER NYL 1/8X1/4 (AT Q14-17)
1 014689 XSTR N-CH JFET J111 TO-92 Q1
1 025748 XSTR NPN 2SC1567 TO-126 Q8
3 016739 XSTR NPN 2N4401 TO-92 Q12,27,28
4 025751 XSTR NPN 2SC2362K TO-92 Q2,3,4,10
4 025744 XSTR NPN MJ15022 TO-3 Q18,20,22,24
1 014408 XSTR NPN MPSA63 TO-92 Q29
1 014867 XSTR NPN MPSU10 TO-202 Q11
2 027745 XSTR NPN NEC 2SC2336B TO-220 Q14,15
2 016742 XSTR PNP 2N4403 TO-92 Q13,36
3 025752 XSTR PNP 2SA1016K TO-92 Q5,6,9
4 025745 XSTR PNP MJ15023 TO-3 Q19,21,23,25
1 014866 XSTR PNP MPSU60 TO-202 Q7
2 027744 XSTR PNP NEC 2SA1006B TO-220 Q16,17
REAR PANEL
POWER AMP ASSEMBLY
1 037883 POWER AMP ASSY 120V (DOMESTIC)
1 026038 BUSHING SR .625X.062X37/64 BLX (100/120V PWR CORD)
1 010401 BUSHING SR .625X.125X37/64 WHT (220/240V PWR CORD)
1 026541 CABLE ASSY POWER CORD (100V/120V)
1 033331 CABLE ASSY POWER CORD (220V/240V)
1 012473 FAN 115V 4-1/8"
1 033576 GASKET FAN 4.9X4.9
2 032900 JACK PHONE 1/4" HI CURRENT (SPEAKER OUTPUT)
PARTS LIST
REAR PANEL
POWER AMP ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
2 016352 NUT HEX 3/8-32X3/32 TK NI (SPEAKER OUTPUT JACK)
6 069393 NUT HEX 6-32 EXT LOCK (FAN,RECTIFIER,GND)
1 049155 PANEL REAR POWER AMP SR6520PD 037998 = SR6520P
1 049156 PANEL REAR POWER AMP SR8520PD 037999 = SR8520P
1 032925 RECTIFIER BRIDGE DIODE
11 031184 SCREW M 6-32X1/4" PHPS BLX
5 015627 SCREW TF 6-32X3/4" PHP BLX (FAN/RECTIFIER MNT)
4 025804 STANDOFF 6-32X1/2" RND AL
1 026479 SWITCH ROCKER DPST (POWER SWITCH)
2 031153 WASHER FLAT 3/8X.614 NI (SPEAKER JACK)
2 9904300100 WASHER LCK INTL 3/8X.681X.032 ZI (SPEAKER JACK)
2 026401 WASHER SHLDR FIBER 3/8X5/8 (OUTPUT JACKS)
CABINET ASSEMBLY
1 049150 CABINET ASSY SR6520PD (COMPLETE CABINET)
1 049151 CABINET ASSY SR8520PD (COMPLETE CABINET)
1 040951 CABINET ASSY SR6520P (COMPLETE CABINET)
1 040952 CABINET ASSY SR8520P (COMPLETE CABINET)
8 031867 CORNER 2 HOLE W/NOTCH BLK PWDRD
4 027849 GLIDE CAB 1.24X.335 BLX (STEEL 18GA)
4 019275 GLIDE CUSHION INSERT (RUBBER)
1 027846 HANDLE 9.25" NO LOGO (RUBBER)
2 031845 HANDLE CAP 2-3/16" BLK PWDRD
1 032524 HANDLE INSERT (SPRING STEEL)
4 021972 NUT T 10-32X3/4 STR 3 PRNG BLX (HANDLE MOUNTING)
4 017393 SCREW M 10-32X1-1/8 OHP BLX (HANDLE MOUNTING)
12 026576 SCREW SMA 8X5/8" TH BLACK (CORNER MOUNTING)
4 026625 SCREW WOOD 8X1" FH (GLIDE MOUNTING)
