Fender SR-8520 - Parts List - Miscellaneous and Digital Reverb; Miscellaneous and Digital Reverb Parts

PARTS LIST
MISCELLANEOUS
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 031882 CLIP W/ADHESIVE (RIBBON CABLE MOUNT)
4 029821 EYELET RFLNGD .215 OD X.315 L (REVERB PAN MOUNTING)
4 026201 GROMMET RUBBER (REVERB PAN MOUNTING)
1 069393 NUT 6-32 HEX EXT LOCK (XFORMER GND WIRE)
1 038531 OWNER'S MANUAL SR6520P/8520P
1 033542 REVERB UNIT 4 SPRING 4BB3S1D (PAN) (SR6520/8520/P)
1 041875 DIGITAL REVERB CONTROL PCB ASSY (SR6520PD/8520PD)
1 041092 DIGITAL REVERB PCB (SR6520PD/8520PD)
1 031184 SCREW M 6-32X1/4" PHPS BLX (XFORMER GND WIRE)
4 029828 SCREW PB 8X3/4" PHP ZI (REVERB PAN MOUNTING)
11 9904101110 SCREW PB 8X5/8" PHP (FRONT/REAR PANEL MT)
1 017439 SCREW SMA 6X1/2" PHP BLX
4 036496 SCREW TF 10-32X1-1/2" PHP BLX (TRANSFORMER MOUNT)
1 031707 TRANSFORMER POWER (DOMESTIC 120V)
1 033210 TRANSFORMER POWER (100V/220V/240V)
4 9904300900 WASHER FLAT 1/4X1" STEEL BLX (TRANSFORMER MOUNT)
PARTS LIST
DIGITAL REVERB CONTROL
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 041092 PCB UNIT DSP REVERB (DIGITAL EFFECTS UNIT W/OUT
CONTROL BOARD)
2 041818 BRACKET RT ANGLE (DIG REV CONTROL BOARD MNT)
1 041814 CABLE 10CKT X 101MM W/CONNECT @P3
1 041815 CABLE 12CKT X 101MM W/CONNECT @P2
2 038703 CAP CA .1µF 50V C4,5
1 027278 CAP MPF .1µF 63V 10% C11
1 027281 CAP MPF .22µF 63V C7
3 028461 CAP AE RDL 10µF 35V 20% C1,2,3
4 028465 CAP AE RDL 22µF 25V 20% C6,8-10
8 006260 DIODE 1N4448/1N914B SIGNAL CR1-8
2 041074 ENCODER 16 POS BI S1,2
1 041816 HEADER 8CKT RT ANG P1
1 028120 IC 4053B TPL 2 CHAN ANLG SW U5
1 031611 IC DUAL OP AMP PC4560 U4
2 041812 IC REGULATOR +5V MC7805CT U1,2
1 041813 IC REGULATOR -5V MC7905CT U3
1 041878 PCB ASSY DIG REV CONTROL PX22 (STUFFED)
1 041876 PCB FAB DIGITAL REV CONTROL (RAW BOARD)
3 024965 RES CF 1/4W 5% 1K R1,2,15
1 024971 RES CF 1/4W 5% 2.2K R4
2 024977 RES CF 1/4W 5% 4.7K R3,11
6 024981 RES CF 1/4W 5% 10K R6,7,8,9,13,14
2 024987 RES CF 1/4W 5% 22K R5,10
1 025081 RES CF 1/4W 5% 5.6M R12
1 025069 RES CF 1/4W 5% 1M
4 032908 SCRW TF 6-32X3/8 PHP ZI (PCB MOUNT)
3 016742 XSTR PNP 2N4403 TO-92 Q1-3
7
