FENDT BALER Series User Manual

SAFETY
A-26 700735021 E Rev.
FIG. 60: SMV (Slow Moving Vehicle) emblem (5)
FIG. 61: Parking brake (6) (if equipped)
(A) Turn the handle counterclockwise to release the
parking brakes.
(B) Turn the handle clockwise to apply the parking brakes.
Do not use more than 40 daN (90 lbf) on the handle.
FIG. 62: Ejector and roller bale chute (7)
The decal will only be on ejector equipped balers.
FIG. 63: Yellow reflector strip (8)
FIG. 60
5
smv2
FIG. 61
700725581b
6
A B
FIG. 62
700730798
7
FIG. 63
700717403
8
