5. Exterior structure
31
5.4 Toilet ap
To open
• Unlatch the lock
j
with the key.
• Press the knob
k
and swing the ap to the side.
To close
• Push the toilet ap to the side until it snaps in.
• Latch the lock
j
with the key.
5.5 Gas-bottle container ap
To open
• Unlatch the lock
j
with the key.
• To unlock, turn the knob that pops out in a counter-clockwise
direction and open the gas-bottle container lid.
1
2
The illustration may vary from the actual ap,
depending on the model and version.
To close
• Shut the lid of the gas-bottle container.
• Press down lightly on the handle of the lid to ensure it ts
snugly on the rubber gasket.
• Latch the lock
j
with the key.
• Press the knob until it snaps in and secure it.
Do not use the push-and-pull lock to open or close the
gas container ap. There is a danger that the locking
system will be damaged.
Note that, due to the scissor-shaped mounting k, there
is a danger of crushing your ngers when opening and clo-
sing the lid of the gas-bottle container.
Please note that if the front window is open, the gas-
bottle container ap should not be opened or only ope-
ned with care. If the window is open at a certain angle,
the gas-bottle container lid may collide with the win-
dow as it swings up.
Please grease and oil the rotary disc/lock rods as re-
quired
l
. Maintain the seals
m
of the service ap by
spraying them regularly with silicone.
2
3
4
1
