6. Interior structure
37
Converting the round seating arrangement into a bed
(Opal 560 SRF)
The levelling cushions (
*
) are included separately and
must be stowed away when the arrangement is in the
seating position.
Position the lowered table in the middle of the seating
arrangement. Do not leave it in the transport or driving
position.
•
Place the cushions as shown in the picture on the left.
1
1
2
Converting the seating arrangement (dinette) into a
bed (515 SGE)
• Fold in the articulated support leg and place the table top on
the designated support bars between the seating benches.
• Fold out the support bracket
j
.
• Place the cushions as shown in the drawing on the left.
Extending the table
(optional extra)
• To extend the table, loosen the knurled screw
j
and pull out
the tabletop. Then tighten the knurled screw.
• To convert this into a bed, the tabletop must be pulled out some-
what to enable it to be removed from the hang rails.
• When converted to seats, cover the openings provided for
lowering the tabletop with the enclosed wooden panel
k
.
Otherwise, loose objects could fall into these openings (this also
applies for various other models with a hinged table).
(465 TG / 515 SD / 465 SFH)
• Release the bolting device on the pillared table frame.
• Lower the table frame.
• Place the cushions as shown in the drawing on the left.
*
*
