8. Water
80
Never operate the therme electrically when it is empty.
WARNING:
The block circuit diagram only reects the function.
Due to the various oor plans, individual modications
are possible.
Emptying the therme:
• Switch o the electricity for the water pump by pressing the
control panel
l
of the main switch for 5 seconds.
• Open all faucets
k
.
• Set all pre-mixing valves to "warm" if necessary.
• Open the drain valves
m
(tilting or rotating head).
3 to 4 drain valves (depending on the layout/model) are directly
next to the therme; another 2 are on the opposite side.
• Check that the water is actually draining o.
• Close the runo valve
m
after emptying (if necessary, blow the
line out).
Electric operation:
• Use the switch
l
to turn on the therme. Use the thermostat to
regulate the water temperature to approx. 55° C.
• Power consumption: approx. 300 W.
Rules for the therme:
• Switch the device o when the caravan is not being used.
• Empty the therme at the risk of frost. Frozen water can cause
the therme to burst!
• A depressuriser must be used if the pump is connected to a
central water supply, or on stronger pumps. The pressure in the
therme may not exceed 1.2 bar. In addition, a safety valve or
runo valve
j
must be used in the cold water tap.
• We recommend that you do not use the water from the therme
as drinking water.
Plan for warm water supply
2
1
3
4
