1.9 Safety devices
1.9.1 Wheel chocks
When you park the machine for storage or
maintenance you must install wheel chocks.
The installation of wheel chocks is very
important when you park the machine on a
slope.
Wheel chocks stop unwanted movement of the
machine. Put the chocks in the position shown.
When you do maintenance and lift the machine,
you must install chocks against the wheels or
tracks that stay on the ground.
GUID-13B8D66E-1FE2-4F83-920B-74848803F132-high.jpg [High]
Fig. 27
1.9.2 Emergency exit and emergency exit tool
The emergency exit tool is installed above the
control console on the right side of the cab. In an
emergency, use the emergency exit tool to break
the right side window and then use the opening as
an exit.
GUID-8590C06A-8153-4BF7-B29A-AFF8B98F0DC8-high.jpg [High]
Fig. 28
1.9.3 Seat belts
Put on the seat belt. Push the connector into the buckle until you hear a click and the connector locks in.
Pull the seat belt to adjust it and make sure that it is not loose.
To release the seat belt buckle, push the button in the center of the buckle. Remove the connector from
the buckle.
To keep the seat belts in good condition:
• Keep all items that are sharp and that can cause damage away from the seat belts.
• Examine the seat belts, buckles and the fasteners for damage, cuts and holes. Replace all damaged
parts.
• Make sure that the seat belt fasteners are tight.
• Make sure that the seat belts are clean and dry.
IMPORTANT: Do not clean the seat belts with solvents, this can make them weak. Only clean the seat
belts with soap and warm water.
Related Links
Operator's seat page 251
[V]
GUID-9F207F62-A929-4D17-9318-11119DDFABCE [V1]
GUID-9A05D543-30B1-48AC-9835-8505E06A1188 [V1]
GUID-5B202234-4F97-4B09-A64D-566FDC4F020D [V1]
1. Safety
IDEAL Series Combine 49
ACX2738370
