ALYX COMPONENT COLLECTION SYSTEM OPERATOR’S MANUAL
CHAPTER 5 – TROUBLESHOOTING
07-19-01-518 – January 2009 5-17
The table below provides alarm icons and their description.
Icon Description Icon Description Icon Description
Air in Line Check Centrifuge Check Plasma
Line from
Centrifuge for
Redness
Check
Venipuncture
Check Elbow Air in AC Line
Check for Kink
in Line
Close Clamp Check Kit for
Leaks
Open Clamp Scale has been
Disturbed
Check Pressure
Cuff
IVD Limit
Exceeded
Disconnect the
Donor
Check Cassette Check AC Power
Connection
Remove Kit
Check Container
Loading
Check Cannulae Power Cycle
Instrument
Expired Kit Icon Battery Charge
Problem
Call for The
Hotline/Service
Bar Code Error Check Filter
Alarm Icon
Legend
