Fenwal 4R5707 - Universal Instrument Markings

07-19-01-518 – January 2009
The following table provides a list of universal markings that may
be seen on the
meanings. This list does not include unique kit or instrument
icons, prompts, or buttons seen on the instrument’s housing, kit,
or displayed on the touch screen. For a complete list of unique
icons, prompts, and buttons used wi
the Glossary of Graphics.
Universal
Instrument
Markings
ALYX COMPONENT COLLECTION S
YSTEM
The following table provides a list of universal markings that may
be seen on the
ALYX instrument
labeling, along with their
meanings. This list does not include unique kit or instrument
icons, prompts, or buttons seen on the instrument’s housing, kit,
or displayed on the touch screen. For a complete list of unique
icons, prompts, and buttons used wi
th the ALYX
System, refer to
the Glossary of Graphics.
Symbol Explanation
Fragile
Attention! See instructions for use.
Keep dry.
This way up.
Storage temperature range.
Storage humidity range.
Batch code (lot #).
Catalog number.
!
