Ferm PDM1027 - Assembly and Usage Instructions; Mounting and Removing Drill Bits and Accessories; Operating the Impact Drill; Tips for Optimum Use

6
EN
ASSEMBLY
4
Before assembly, always switch off the
machine and remove the mains plug
from the mains.

The machine is suitable for use of the following
drill bits:
- Wood(HSS)
- Metal(HSS)
- Concrete/masonry(hardmetal)
Mounting
● Openthechuck(6)byturningthecollar(11)
counterclockwise.
● Insertthedrillbit(12)intothechuck(6).
● Closethechuck(6)byturningthecollar(11)
clockwise.
Removing
● Openthechuck(6)byturningthecollar(11)
counterclockwise.
● Removethedrillbit(12)fromthechuck(6).
● Closethechuck(6)byturningthecollar(11)
clockwise.

Mounting
● Loosentheauxiliarygrip(8).
● Slidetheauxiliarygrip(8)overthechuck(6).
● Turntheauxiliarygrip(8)totherequired
position.
● Tightentheauxiliarygrip(8).
Removing
● Loosentheauxiliarygrip(8).
● Removetheauxiliarygrip(8)fromthechuck(6).
● Tightentheauxiliarygrip(8).

The depth stop is used to set the maximum
drilling depth.
Mounting
● Loosentheauxiliarygrip(8).
● Insertthedepthstop(9)throughtheholein
the auxiliary grip (8).
● Setthedepthstop(9)totherequiredposition.
● Tightentheauxiliarygrip(8).
Removing
● Loosentheauxiliarygrip(8).
● Removethedepthstop(9)fromtheauxiliary
grip (8).
● Tightentheauxiliarygrip(8).
USE

● Toswitchonthemachine,presstheon/off
switch(1).Thefurthertheon/offswitch(1)is
pressed, the higher the speed of the machine.
● Toswitchthemachinetocontinuousmode,
keeptheon/offswitch(1)pressedand
simultaneouslypressthelock-onbutton(2).
● Toswitchoffcontinuousmode,pressthe
on/offswitch(1)again.
● Toswitchoffthemachine,releasetheon/off
switch (1).

2
Do not change the direction of rotation
during use.
● Forclockwiserotation,slidetheforward/
reverse switch (4) to the left.
● Forcounterclockwiserotation,slidethe
forward/reverseswitch(4)totheright.

2
Do not set the speed during use.
● Turnthespeedadjustmentwheel(3)clockwise
to increase the maximum drilling speed.
● Turnthespeedadjustmentwheel(3)
counterclockwise to decrease the maximum
drilling speed.

2
Do not change the operating mode
during use.
● Settheswitch(5)toposition„A“fordrilling.
● Settheswitch(5)toposition„B“forhammer
drilling.
Hints for optimum use
● Clamptheworkpiece.
● Firmlyholdthemachinewithbothhands.
● Placethedrillbitontheworkpiece.
● Switchonthemachine.
● Donotapplytoomuchpressureonthe
machine.Letthemachinedothework.
● Switchoffthemachineandwaitforthe
machine to come to a complete standstill
before putting the machine down.
