PLANER
The numbers in the following text correspond
with the pictures at page 2 - 3.
Read through these operating
instructions carefully before using the
appliance. Become familiar with the
functions and method of operation. To
ensure proper operation, always maintain
the appliance according to the
instructions. The operating instructions
and associated documents should always
be kept close to the appliance.
Product description
This doubly insulated electric tool is designed to
be manually operated. It has an appealing shape
and small dimensions, which facilitate easy
transportation. It is safe and reliable when in
operation. It is driven by a single phase electric
motor via a V-belt. It is suitable for planing wooden
beams or boards and also for bevelling and
rebating.
Contents
1. Technical data
2. Safety instructions
3. Operation
4. Care and maintenance
1. Technical data
Voltage 230 V~
Frequency 50 Hz
Power consumption 900 W
Number of revolutions, idle 15000/min
Maximum planing width 82 mm
Maximum planing depth 2.5 mm
Maximum rebating depth 18 mm
Weight 3.2 kgs
LpA (sound pressure) 87.9 dB(A)
LwA (sound capacity) 98.9 dB(A)
Vibration value 3.44 m/s
2
Vibration level
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardised test given in
EN 60745; it may be used to compare one tool
with another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned
- using the tool for different applications, or with
different or poorly maintainted accessories,
may significantly increase the exposure level
- the times when the tool is switched off or when
it is running but not actually doing the job, may
signifi cantly reduce the exposure level
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns
Parts list
Fig. 1 + 2
A. Control knob for adjustment of planing depth
B. Indication of planing depth
C. Protective guard
D. Operating Switch
E. Release Button
F. Handle
G. Cover, left
H. Rebating depth stop with locking nut
K. Planer shoe with V-groove
L. Dustbag connection
2. Safety instructions
Explanation of symbols
In this manual and/or on the machine the following
symbols are used:
In accordance with essential applicable
safety standards of European
directives
Class II machine – Double insulation –
You don’t need any earthed plug.
Denotes risk of personal injury, loss of
life or damage to the tool in case of non-
observance of the instructions in this
manual.
Indicates electrical shock hazard.
Remove the plug from the mains
Wear a dust mask. Working with wood,
metals and other materials may produce
dust that is harmful to health. Do not work
with material containing asbestos!
