Ferm psm1026 - DESCRIPTION (Fig. A)

6
Ferm
EN

Ifthemoulded3-pinplugattachedtotheunitis
damagedandneedsreplacing,itisimportantthat
itiscorrectlydestroyedandreplacedbyan
approvedBS1363/3Afusedplugandthatthe
followingwiringinstructionsarefollowed.
Thewiresinthemainscablearecolouredin
accordancewiththefollowingcode:
blue neutral
brown live
Asthecoloursofthewiresinthemainscableof
theunitmaynotcorrespondtothecoloured
markingsidentifyingtheterminalsintheplug,
proceedasfollows:
- Thewirewhichiscolouredbluemustbe
connectedtotheterminalwhichismarkedwith
theletterNorcolouredblack.
- Thewirewhichiscolouredbrownmustbe
connectedtotheterminalwhichismarkedwith
theletterLorcolouredred.
TECHNICAL DATA
PSM1026
Mainsvoltage V~ 230
Mainsfrequency Hz 50
Powerinput W 135
No-loadspeed min
-1
 10,000
Protectionclass  IP20
Weight kg 1.3
NOISE AND VIBRATION
PSM1026
Soundpressure(L
pa
) dB(A) 73
Acousticpower(L
wa
) dB(A) 84
Uncertainty(K) dB(A) 3
Vibration m/s
2
 12.11
Uncertainty(K) m/s
2
 1.5
2
Wear hearing protection.
Vibration level
Thevibrationemissionlevelstatedinthis
instructionmanualhasbeenmeasuredin
accordancewithastandardisedtestgiveninEN
60745;itmaybeusedtocompareonetoolwith
anotherandasapreliminaryassessmentof
exposuretovibrationwhenusingthetoolforthe
applicationsmentioned
- usingthetoolfordifferentapplications,orwith
differentorpoorlymaintaintedaccessories,
maysignicantlyincreasetheexposurelevel
- thetimeswhenthetoolisswitchedofforwhen
itisrunningbutnotactuallydoingthejob,may
signicantlyreducetheexposurelevel
Protectyourselfagainsttheeffectsofvibrationby
maintainingthetoolanditsaccessories,keeping
yourhandswarm,andorganizingyourwork
patterns

Yournishingsanderhasbeendesignedfor
sandingwood,metal,plasticsandpainted
surfaces.
 1. On/offswitch
 2. Lock-onbutton
 3. Sandingpad
 4. Sandingpaperclamp
 5. Maingrip
 6. Auxiliarygrip
 7. Dustextractionconnection
ASSEMBLY
4
Before assembly, always switch off the
machine and remove the mains plug
from the mains.
Mounting and removing the sanding paper

Mounting
● Openthesandingpaperclamps(4).
● Mountsandingpaper(8)withtherequired
grainsizeontothesandingpad(3).Makesure
thattheperforationinthesandingpaper(8)
correspondswiththeperforationonthesanding
pad(3).
- Usecoarsesandingpaper(grain50)for
sandingrough,unevensurfaces.
- Usemediumsandingpaper(grain80)for
removingtheremainingscratchesfromthe
coarsesandingpaper.
- Usenesandingpaper(grain120)for
nishingsurfaces.
● Foldthesandingpaper(8)atbothends
aroundtheedgesofthesandingpad(3).
● Closethesandingpaperclamps(4)oneby
one.Makesurethattheendsofthesanding
paper(8)areclamped.
