31 / 32 Limit switch with encoder.
Limit switch connection if used with encoder. With DIP-switch No. 1 ON is necessary to
install a close limit switch.
33 / 34 / 35 / 36
Limit switch without encoder.
Limit switch connection if used without encoder. With DIP-switch No. 1 OFF is necessary
to install an open and close limit switch.
37 Motor and encoder.
Output to the 24 DC motor to control speed and torque. The ECC - 230 V motor controller is
formed by a power stage with a feedback speed control circuit with voltage compensation
and current limiting protections (Imax).
38 Test pushbutton.
Operation of the Test pushbutton will cause a door open or close cycle.
39 Safety.
La velocità di apertura della porta può essere regolata da 100 mm/s no a 300 mm/s.
40 Close speed.
The door closing speed can be independently adjusted from 100 mm/s up to 300 mm/s.
41 Open speed.
The door opening speed can be independently adjusted from 100 mm/s up to 300 mm/s.
42 On / Off switch.
Disconnects the unit from the 230 V AC mains supply.
POWER SUPPLY
• DC voltage range 230 V +10%, -15%. AC/DC.
• Minimum power 83 mA 2,8 W.
• Average power (240 cycles/hour) 0,17 A 14,7 W.
• Maximum power 0,27 A 33,7 W.
PWM REGULATION
• PWM frequency 15KHz.
• Voltage range 0...24 V DC III.
• Maximum output current 2 A.
• Positional control: Quadrature encoder.
MOTOR
• Brushed DC motor
• Voltage supply 24 V.
• Power 7 W.
• Enclosure class IP 20.
• Nominal speed 17 rpm.
REFERENCE DATA
INPUTS
