Fermax 5293 - Technical Data; Operation Modes; Installation Guide

Cod. 970030 V04_20
6
REF. 5293 KEYPAD RESISTANT
Installer manual EN
Technical data
Keypad with Proximity reader RESISTANT
Model
Keypad with Proximity reader RESISTANT
User capacity (autonomo)
600
Operating system
2-5cm aprox
Power supply
12Vac/dc (12~28VDC)
Standby Current
65mA (proximity to metals or between readers affects
consumption)
Compatibility
Cards EM(125khz), HID(125khz), Mifare(13,56Mhz)
Operating frequency
125Khz & 13,56MHz
Rele (in autonomous)
2A (C,NO,NC) 1~99 seconds. (5 seconds. By default)
Watertight
IP66 / IK9
Operating temperature
-20ºC a +60ºC
Dimensions
145x55x20mm
Protocol /operation format
Wiegand 26 / 4-8-10 bits (4bits by default)
Humidity
10% ~ 90%RH
Operation
Autonomous (by default) or centralized (Wiegand 26 – 8bits)
Installation
Read Card
The LED light will turn into Green, and the buzzer sounds a beep,
at the meantime.
Keypad
The reader will transmit the PIN data after every key is pressed + #
