6 DUOX PLUS WIFI VEO XS MONITOR
CONNECTIONS
Dismantling the monitor
The connector is designed to dismantle the monitor
without the need for any tools. To do this, simply pull
at the lower corners perpendicularly to the wall until
the clips are unlocked and a minimum angle of 10
degrees with the wall is reached. Then, unhook the
monitor from the hooks at the top of the connector.
a
a) Wall installation
If the monitor is attached to the connector but the
connector is not anchored to a wall, you will need
to use a flat-head screwdriver to prise them apart
as indicated.
b
b) Monitor attached to connector
