Pag 34
Select operating mode
To confi gure a Guard Unit as Panic Alarms Reception Centre, and select
the alarm reception mode:
1. Key in "0" to enter programming mode.
The display shows a series of dashes.
2. Press "B" and "3" repeatedly, until the dashes are completed
and the display shows the current operating mode.
3. Use the arrow keys to select the desired operating mode.
NIGHT
DAY
TRANSFER (*)
MASTER(*)
(*) Only available in facilities with several Central Units (blocks).
See NOTE on the following page.
4. Press "B" when the desired operating mode comes up on
the display.
0
3
3
B
+
.
.
.
B
B333_ _
NOTE:
If the chosen mode is: TRANSFER, you will need to indicate which
block number the calls are to be transferred to. The number of each
Guard Unit was installed at the moment of installation.
