Fermax VDS User Manual

4 VDS VIDEO KIT CITYLINE 1-2 L SMILE TOUCH SCREEN
VDS
MONITOR TECHNICAL CHARACTERISTICS (7” touch screen)
Power supply 18 Vdc
Consumption
in standby 45 mA
audio + video 720 mA
in menu 450 mA
Operating temperature [-5º , +40ºC]
Humidity 5% - 95%
50 - 100
100 - 200
75 Ohm
75 Ohm
75 Ohm
mm
mm2,5
1,5
2
2
S
metros / metres
pies / feet
AWG
150 - 300
mm
2
15
13
D
300 - 600
1 - 50
mm1
2
3 - 150 17
50 - 100 mm1,5
2
S
metros / metres
pies / feet
AWG
150 - 300
mm
2
15
1 - 50
mm1
2
3 - 150 17
UTP CAT5
-
L
V
M
+
BUS 5 hilos
D
BUS 5 wires
TECHNICAL FEATURES
Power Supply 18 Vdc
Standby Consumption 57mA
Audio active consumption 210mA
Audio Power in Residence - Entry Panel Direction 1 W
Audio Power in Entry Panel - Residence Direction 0.15 W
Operating temperature [-10º , +60ºC] / [-14º, 140ºF]
Volume can be Regulated in Both Directions
PANEL TECHNICAL CHARACTERISTICS
PANEL VALUES
Lock-release activation time 01...99 sec. (Default: 03)
Exit button activation time 00...99 sec. (Default: 06)
MASTER Panel active
DIAGRAMS
SECTIONS-DISTANCES TABLE
This kit may be installed with 3 wires + COAXIAL, or with the 5 wire BUS with the indicated
section in the table, or UPT CAT5 cable (Category 5), see sections - distances table.
Table: 3 wires + COAXIAL
Table: BUS 5 wires / UTP CAT5
