Ferno 125 - Storing the Adjusta-Pad and Head Straps; Storing the Torso Flaps

30
© Ferno-Washington, Inc. 234-1754-02 April 2001
ADJUSTA-PAD
Lay the KED flat with the buckles facing upward. Place
the Adjusta-Pad on the center of the KED, with one
end of the pad at the bottom edge of the KED (Figure
53).
HEAD STRAPS
Press one end of each strap against the hook-and-loop
fastening strips on the head area of the KED and lay
the straps parallel with the Adjusta-Pad.
Figure 54 - Folding the Torso Flap
Figure 55 - Rolling the KED
Figure 56 - Ready for the Carrying Case
Figure 53 - Positioning the Adjusta-Pad
And Head Straps
TORSO FLAPS
1. Fold the torso flap over the Adjusta-Pad, tucking
the edge of the flap over the edge of the pad
(Figure 54).
2. Roll the folded portion of the KED over the
remaining torso flap (Figure 55) until the center
portion of the inside of the KED is upward (Figure
56).
3. Grasp the KED to keep it rolled and slide it into
the carrying case.
Model 125 KED
Storing the KED
