52cc 2 Stroke Brushcutter / Line Trimmer
AFTER SALES SUPPORT
e-mail: info.aldi@positecgroup.com
1300 889 028
MODEL: №. SBC52 • 02/2020 • 700710
(toll free)
20
Fitting the Spool and Line Assembly on the Line Trimmer
NOTE: If the unit has been used as a brushcutter rst, the brushcutter blade
will need to be removed before tting the spool and line assembly.
Refer to “Changing/Removing the Brushcutter Blade” for instructions on how
to remove the blade.
NOTE: Always ensure the engine is turned o before undertaking this
assembly.
1. Lay the unit down so that the fuel tank bracket (39) is facing upwards and
the engine is resting on the ground. Lift the gearbox end of the lower
shaft (15) to gain access to the spindle (20).
IMPORTANT: Ensure the inner ange is mounted on the spindle of the line
trimmer. The outer ange (29), the protector (27), the 3T brushcutter blade
(28) and the blade nut (26) are NOT required when the line trimmer spool &
line assembly (35) is being tted.
Keep these components in a safe place. The 3T brushcutter blade (28)
should be placed back in the cardboard packaging/envelope.
2. Place the spool and line assembly (35) on the
spindle (20) and thread on to the spindle nger
tight in an anti clockwise direction all the way
down until the back of the spool makes contact
with the inner ange (30) (Fig W).
3. Insert the long end of the supplied 4mm allen
key (37) through the spindle lock entry hole (19)
and into the hole on the inner ange (30).
(This locks the spindle allowing the spool and
line assembly (35) to be secured). Further tighten
the spool and line assembly (35) ensuring the
assembly is tight on the spindle (20) and inner
ange (30) before removing the 4mm allen key
from the spindle hole to release the spindle
being locked (Fig. X).
4. To remove the spool and line assembly (35),
follow this procedure in reverse.
A.
A.
X.
W.
