Ferris 5900619 - Mowing Height Adjustment

43
Troubleshooting
Troubleshooting, Adjustment & Service
MOWING HEIGHT ADJUSTMENT
The cutting height adjustment pin (A, Figure 39)
controls the mower cutting height. The cutting height
is adjustable between 1-1/2” (3,8 cm) and 6” (15,2
cm) in 1/4” (0,64 cm) increments.
1. Depress the deck lift foot pedal (B) until it locks
into the 6” (15,2 cm) position.
2. Place the cutting height adjustment pin in the
desired cutting height.
3. Depress the deck lift foot pedal then push the lock
lever (C) towards the right to release the lock.
4. Release the deck lift foot pedal until it comes to
rest against the cutting height adjustment pin.
B
Figure 39. Mowing Height Adjustment
A. Cutting Height Adjustment Pin
B. Deck Lift Foot Pedal
C. Deck Lift Lock lever
C
A
