6.9 For Serviceman
OPERATION PARAMETER
#01
OPERATE MODE COOL
ADDRESS
SV1 STATE ON
The power consumption parameter is optional. If some parameter
is not be activated in the system, the parameter will show "--"
The heat pump capacity is for reference only, not used to judge
the ability of the unit. The accuracy of sensor is ±1℃. The flow
rates parameters are calculated according to the pump running
parameters,the deviation is different at different flow rates,the
maximum of deviation is 15%.The flow parameters are calculated
according to the electrical parameters of the pump operation.
The operating voltage is different and the deviation is different.
The display value is 0 when the voltage is less than 198V.
INFORMATION
i
6.9.1 About For Serviceman
FOR SERVICEMAN is used for installater and service
engineer.
Setting the function of equipment.
Setting the parameters.
6.9.2 How To Go To For Serviceman
Go to ''MENU'' > ''FOR SERVICEMAN''. Press ''OK''.
ONLINE UNITS NUMBER 1
SV2 STATE OFF
SV3 STATE OFF
PUMP_I ON
1/9
OPERATION PARAMETER
#01
PUMP_C OFF
ADDRESS
PUMP_S OFF
PUMP_O OFF
PUMP_D OFF
PIPE BACKUP HEATER OFF
TANK BACKUP HEATER ON
2/9
OPERATION PARAMETER
#01
T1 LEAVING WATER TEMP. 35°C
ADDRESS
WATER FLOW 1.72m
3
/h
GAS BOILER OFF
HEAT PUMP CAPACTIY 11.52kW
POWER CONSUM 1000kWh
Ta ROOM TEMP. 25°C
3/9
OPERATION PARAMETER
#01
Tw2 CIRCUIT2 WATER TEMP. 35°C
ADDRESS
TIS’ C1 CLI. CURVE TEMP. 35°C
T5 WATER TANK TEMP. 53°C
TIS2’ C2 CLI. CURVE TEMP. 35°C
TW_O PLATE W-OUTLET TEMP. 35°C
TW_I PLATE W-INLET TEMP. 30°C
4/9
OPERATION PARAMETER
#01
Tbt2 BUFFERTANK_LOW TEMP. 35°C
ADDRESS
IDU SOFTWARE 01-09-2019V01
Tbt1 BUFFERTANK_UP TEMP. 35°C
5/9
OPERATION PARAMETER
#01
COMP.CURRENT 12A
ADDRESS
COMP.FREQENCY 24Hz
ODU MODEL 6kW
COMP.RUN TIME 54 MIN
COMP.TOTAL RUN TIME 1000Hrs
EXPANSION VALVE 200P
6/9
OPERATION PARAMETER
#01
IDU TARGET FREQUENCY 46Hz
ADDRESS
FREQUENCY LIMITED TYPE 5
FAN SPEED 600R/MIN
SUPPLY VOLTAGE 230V
DC GENERATRIX VOLTAGE 420V
DC GENERATRIX CURRENT 18A
7/9
OPERATION PARAMETER
#01
TW_I PLATE W-INLET TEMP. 30°C
ADDRESS
T2 PLATE F-OUT TEMP. 35°C
TW_O PLATE W-OUTLET TEMP. 35°C
T2B PLATE F-IN TEMP. 35°C
Th COMP. SUCTION TEMP. 5°C
Tp COMP. DISCHARGE TEMP. 75°C
8/9
OPERATION PARAMETER
#01
T4 OUTDOOR AIR TEMP. 5°C
ADDRESS
TF MODULE TEMP. 55°C
T3 OUTDOOR EXCHARGE TEMP. 5°C
P1 COMP. PRESSURE 2300kPa
ODU SOFTWARE 01-09-2018V01
HMI SOFTWARE 01-09-2018V01
9/9
Tsolar 25°C
Please input password:
2 3 4
ENTER
OK
FOR SERVICEMAN
ADJUST
