Festo KBS-FEC FC30- 0206NH English38
Serial ports
Number 2
Connection RJ12 socket
Properties serial, asynchronous, TTL level
not electrically isolated
As an RS232C SM14/SM15 port adapter re-
quired
SM14/15 terminal assignment Transmit, Receive, RTS, CTS
As a progra mming interf ace 9600 baud, 8/N/1
As a universal interface: COM 300 ... 9600 baud, 7N1, 7E1, 7O1,
8N1, 8E1, 8O1
1.)
As a universal interface: EXT 300 ... 115000 baud, 7N1, 7E1,
7O1, 8N1, 8E1, 8O1
1.)
1)
The specifications from the development environment should be observed.
Status display
Power LED Operating voltage display - Green
Status LED According to the status:
Run - Green / Stop - Orange /
Error - Red
