Operating and Ambient Conditions
Individual valve fastened with screws: SG2
Individual valve on H-rail: SG1
Linking of max. 3 valves with lateral screw mounting: SG2
Vibration (part 2-6)
Linking of max. 5 valves with lateral screw mounting: SG1
Individual valve fastened with screws: SG2
Individual valve on H-rail: SG1
Linking of max. 3 valves with lateral screw mounting: SG2
Shock (part 2 – 27)
Linking of max. 5 valves with lateral screw mounting: SG1
Tab. 13 Operating and Ambient Conditions
Features of severity level (SL)
Vibration load
Frequency range [Hz] Acceleration [m/s
2
] Deflection [mm]
SL1 SL2 SL1 SL2 SL1 SL2
2…8 2…8
– –
±3.5 ±3.5
8…27 8…27 10 10
– –
27…58 27…60
– –
±0.15 ±0.35
58…160 60…160 20 50
– –
160…200 160…200 10 10
– –
Shock load
Acceleration [m/s
2
] Duration [ms] Shocks per direction
SL1 SL2 SL1 SL2 SL1 SL2
±150 ±300 11 11 5 5
Continuous shock load
Acceleration [m/s
2
] Duration [ms] Shocks per direction
±150 6 1000
Tab. 14 Features of severity level (SL)
Pneumatic Characteristic Values
Input pressure at (1)
1)
Operating pressure at (1)
2)
Product type
[MPa] [bar] [MPa] [bar]
VPPI -...- 1V0H -... 0…0.6 0…6 0…0.2 0…2
Technical Data
24 Festo — VPPI-...-D — 2019-12
