8
Functional description
The pictures for the functional description are on a
fold-out page at the beginning of the instruction
manual. When reading of the manual you can fold
out this page for having always an overview of the
machine.
Intended use
The dust extractor is designed for use as specified
for the aspiration and evacuation of non-noxious
dusts, dirt, sand, shavings etc..
The dust extractor is designed as specified for vac-
uuming water.
The dust extractor is designed for household, com-
mercial or both use.
Filter surface 6318 cm² (979.3 sq.in.)
Suction hose (diameter x length) 27 mm x 3,5 m (1.06 in. x 11.48 in.)
Protection type IP X4
Sound pressure level as per IEC 60704-2-1 71 dB(A)
Container capacity CT 26 E 26 l (6.9 gal.)
CT 36 E 36 l (9.5 gal.)
Dimensions L x W x H CT 26 E 630 x 365 x 540 mm
(24.8 in. x 14.4 in. x 21.3 in.)
CT 36 E 630 x 365 x 596 mm
(24.8 in. x 14.4 in. x 23.5 in.)
Weight CT 26 E 13 kg (28.6 lbs)
CT 36 E 13,5 kg (29.7 lbs)
1.
) 8.3 A (1000 W) is the medium value for different operation conditions, a maximum power consumption of 10 A (1200 W) is possible.
2.
) When the suction power adjuster [1-7] is adjusted to the lowest suction power (see page 10, chapter Settings - Adjusting the suction
power) the maximal rating of a connected power tool can be 9.1 Amps.
Dust extractor CT 26 E, CT 36 E
[1-1]
Intake opening
[1-2]
Module slot
[1-3]
Appliance socket
[1-4]
Hose store
[1-5]
Handle
[1-6]
SysDoc
[1-7]
Suction power adjuster
[1-8]
Switch
[1-9]
Locking clip
[1-10]
Dust container
[1-12]
Brake
WARNING
The user will be liable for damage due to improp-
er use.
