9
Technical data
Functional description
The pictures for the functional description are on a
fold-out page at the beginning of the instruction
manual. When reading of the manual you can fold
out this page for having always an overview of the
machine.
Accessories shown or described are sometimes not
included in the scope of delivery.
Intended use
The dust extractor is designed for use as specified
for the aspiration and evacuation of non-noxious
dusts, dirt, sand, shavings etc..
The dust extractor is designed as specified for vac-
uuming water.
The dust extractor is designed for household, com-
mercial or both use.
Dust extractor CT 36 E AC
Power consumption (dust extractor only) 2.9 - 8.3 A (350 - 1000 W)
1
.)
Total connected load max. 12 A (1440 W)
Max. rating of connected Power Tool 3.7 A
2.)
Volume flow (air), turbine max. 234 m³/h (8264 cu.ft./h)
Vacuum, turbine max. 24000 Pa
Filter surface 6318 cm² (979.3 sq.in.)
Suction hose (diameter x length) 36 mm x 3.5 m (1-7/16" x 11.5’)
Protection type IP X4
Sound pressure level as per IEC 60704-2-1 71 dB(A)
Container capacity CT 36 E AC 36 l (9.5 gal.)
Dimensions L x W x H CT 36 E AC 630 x 365 x 596 mm
(24.8 in. x 14.4 in. x 23.4 in.)
Weight CT 36 E AC 15.2 kg (33.5 lbs)
1.
) 8.3 A (1000 W) is the medium value for different operation conditions, a maximum power consumption of 10 A (1200 W) is possible.
2.
) When the suction power adjuster [1-7] is adjusted to the lowest suction power (see page 11, chapter Settings - Adjusting the suction
power) the maximal rating of a connected power tool can be 9.1 Amps.
[1-1]
Intake opening
[1-2]
Module slot
[1-3]
Appliance socket
[1-4]
Hose store
[1-5]
Handle
[1-6]
SysDoc
[1-7]
Automatic cleaning
[1-8]
Suction power adjuster
[1-9]
Switch
[1-10]
Locking clip
[1-11]
Dust container
[1-13]
Brake
WARNING
The user will be liable for damage due to improp-
er use.
