4 Technical data
Mobile dust extractors
Power consumption 350 - 1200 W
Max. electrical outlet module connected load EU
CH, DK
GB 230 V/110 V
2400 W
1100 W
1800 W/500 W
Max. suction capacity (air), extractor/turbine 130 m³/h/234 m³/h
Max. vacuum, turbine 24,000 Pa
Filter surface area 6318 cm²
Suction hose (depending on mobile dust extractor version) D27/32x3.5m-AS/CTR
D36x3.5-AS/KS/B/LHS 225
D36/32x3.5m-AS/R
Mains power cable length 7.5 m
Sound pressure level as per EN 60704-2-1/uncertainty K 71 dB(A)/3 dB
Type of protection IP X4
Container capacity CT 26 26 l
CT 36 36 l
CT 48 48 l
Dimensions L x W x H CT 26 630 x 365 x 540 mm
CT 36 630 x 365 x 596 mm
CT 48 740 x 406 x 1005 mm
Weight CT 26 / CT 26 AC 13.9 kg / 14.7 kg
CT 36 / CT 36 AC 14.4 kg / 15.2 kg
CT 48 / CT 48 AC 18.8 kg / 19.6 kg
5 Intended use
Mobile dust extractor suitable for
– extracting dust up to 1 mg/m³ according to
dust class L,
– extracting water,
– for increased loads during commercial use,
according to IEC/EN 60335-2-69.
The user is liable for improper or non-in
tended use.
6 Commissioning
WARNING
Unauthorised voltage or frequency!
Risk of accidents
► Observe the specifications on the ma
chine's name plate.
► Observe country-specific regulations.
6.1 Initial commissioning
► Insert the filter/disposal bag [2].
► Fit the cord holder [3].
► Connect the suction hose [4].
English
16
