– When lifting the saw before the
pendulum guard is closed.
– Touching rotating parts from the side: Saw
blade, clamping flange, flange screw,
– Machine kick-back when it jams in the
workpiece,
– Touching live parts when the housing is
open and the mains plug is still plugged in,
– Workpiece parts being thrown off,
– Parts of damaged tools being thrown off,
– Noise emissions,
– Dust emissions.
3 Intended use
The cross cutting guide rail is designed for
sawing wood and panel materials.
It enables precise and clean cuts, in particular
angled cuts can be performed simply and with
repeat accuracy. The saw automatically moves
back to the initial position after the sawing
process.
This power tool may only be used by experts or
instructed persons.
The user is liable for improper or non-
intended use.
4 Technical data
Cross
cutting
guide rail
FSK 250 FSK 420 FSK 670
Cutting
length
(with
material
thickness
of 50 mm)
250 mm 420 mm 670 mm
Angled
cuts
-45°–
+60°
–60°–
+60°
–60°–
+60°
Weight 0.97 kg 1.25 kg 1.64 kg
5 Commissioning
Before initial use, saw the splinter guard
[1-1]
:
► Position saw with the entire guide plate at
the rear end of the cross cutting guide rail.
► Swivel saw to 0° position and set maximum
cutting depth.
► Switch on saw.
► Slowly drop the splinter guard across the
entire length without setting down.
The edge of the splinter guard now corresponds
exactly to the cutting edge.
6 Assembly
6.1 Connecting the saw to the cross cutting
guide rail
► Slide the saw onto the cross cutting guide
rail in the sawing direction.
The saw engages in the sliding block [1-3].
The quick fastener [1-2] locks in behind the
saw table.
The saw is securely connected to the cross
cutting guide rail.
6.2 Separating the saw from the cross
cutting guide rail
► Push the saw forward slightly in the sawing
direction.
► Turn the quick fastener [1-2] forward.
► Remove the saw by pulling it backward
against the sawing direction.
7 Working with the power tool
Every time before use, check that the
cross cutting guide rail is retracted
correctly
and have it repaired, if necessary.
Never use if automatic retraction is not oper
ating correctly.
7.1 Settings
► Open rotary knob at adjustable stop[2-1].
► Adjust angle at the scale [2-3].
► Close rotary knob at adjustable stop [2-1].
► Adjust cutting depth and cutting angle to
saw.
► Adjust the guide play between the saw table
and the cross cutting guide rail using the
two adjustable jaws [2-2].
The saw must run slightly above the rail.
