Festool OSC 18 User Manual

11-1
11a
USB 78/42/BI/OSC
USB 78/32/BI/OSC
ü
11-2
11b
Readjusting the saw blade guide
First check to ensure that the application tool
has been inserted in the correct order (see fig
ure [10]). If the saw blade is still not positioned
on the saw blade guide, take the following
steps:
► Set the cutting depth [11-1] to the maxi
mum depth. Tighten the cutting depth ad
justment [11-1].
► Loosen the screw [12-1] on the saw blade
guide [12-2].
► Move the saw blade guide to the saw blade.
► Tighten the screw [12-1] on the saw blade
guide.
12-1
12-2
12
12.5 SYSTAINER
Systainer
Many Festool products are shipped in a unique
system container, called "Systainer". This pro
vides protection and storage for the tool and ac
cessories. The Systainers are stackable and
can be interlocked together. They also can be
interlocked atop Festool CT dust extractors.
To open the Systainer
Turn the T-loc [SYS-b-1] to this posi
tion.
To lock the Systainer
Turn the T-loc [SYS-b-1] to this posi
tion.
To connect two Systainers
Place one Systainer on the top of the other
(Fig. [SYS-a]).
Turn the T-loc [SYS-b-1] to one of
this positions (Fig. [SYS-b]).
The Systainers are connected and locked.
A new generation Systainer is connectable
on top of a previous generation Systainer
by the four latches of the previous
Systainer.
English
15

Festool OSC 18 Specifications

General

Input power	- W
Power source	Battery
Battery voltage	18 V
Oscillation angle	2 °
Sound power level	93 dB
Sound pressure level	83 dB
Sound level uncertainty	3 dB
Idle oscillation rate (max)	19500 OPM
Idle oscillation rate (min)	10000 OPM
Battery included	No
Number of plunge-cutting saw blades	1
Product color	Black, Blue
Multi-tool applications	-

Weight and Dimensions

Weight	1800 g
