3/4
C
601/08
Preparation/Set-up
The economical 3-in-1 principle: one machine - three applications
Coarse sanding (also called rotary sanding) •
With this motion the pad is driven using a gear - forced rotation.
With the combination of eccentric and rotary motions the ROTEX
achieves up to three times higher material removal capacity than
other eccentric sanders.
Fine sanding (also called eccentric sanding) •
In this motion the pad rotates itself. You obtain a first-class, extra-fine
sanding pattern with this classic eccentric motion. If the machine
is pressed to hard on the workpiece, the pad sticks - this should be
avoided!. (This will have a negative impact on the sanding result).
Polishing (with the ROTEX rotary motion) •
For this application a rotation is needed so the gear is switched on.
The overlapping rotary and eccentric motions of the ROTEX ensure
optimal results also for polishing.
601/07
601/09
Procedure
To switch the machine from coarse sanding to fine sanding or vice-versa the
motor must be switched off.
The switching is effected via the slide switch located in the centre of the cap. •
If the switch is moved to the right (rough tab), the machine is in coarse •
sanding/rotary mode.
If the switch is moved to the left (fine tab), the machine is in fine sanding/ •
eccentric sanding mode.
E
601/10
