4 Technical data
Cordless drill TXS
Motor voltage 10.8 V
No-load speed*
1st gear
2nd gear
0–430 rpm
0–1300 rpm
Max. torque
soft/hard screwdriving applica
tion 10/16 Nm
Adjustable torque 0.3–3.4 Nm
Chuck clamping range 1–10 mm
Max. drill diameter
Wood/metal 12/8 mm
Tool holder in drill spindle 1/4"
Weight (incl. battery pack and
chuck) as per EPTA procedure
01:2014
1.1 kg
Weight incl. battery pack and
Centrotec
0.9 kg
* Speed values based on fully charged battery
pack.
More technical data about the charg
er and the supplied battery pack can
be found on page 6.
5 Machine features
[1-1]
Drilling symbol
[1-2]
Torque thumbwheel
[1-3]
Torque/drilling position marking
[1-4]
Gear switch
[1-5]
Right/left switch
[1-6]
On/Off switch
[1-7]
Belt clip
[1-8]
Insulated gripping surfaces (grey
shaded area)
[1-9]
Button for releasing the battery pack
[1-11]
Bit store
[1-10]
LED lamp with capacity indicator
[3A]
Wall mount for charger
The specified illustrations appear at the begin
ning of the Operating Instructions.
The specified illustrations appear at the begin
ning of the Operating Instructions.
6 Operation
6.1 Changing the battery pack [2]
Battery pack is ready for use immedi
ately upon delivery and can be charg
ed at any time.
Side of the belt clip [2-1] can be re
placed when battery pack is removed.
6.2 Charging the battery pack [3]
The LED [3-1] on the charger indicates the re
spective operating status of the charger.
LED yellow - continuous
light
Charger is ready to use.
LED green - light flashes
quickly
Battery pack is charged to
maximum capacity.
LED green - light flashes
slowly
Battery pack is charged to
80% and with reduced cur
rent.
LED green - continuous light
Battery pack is charged.
LED red - light flashes
General fault indicator, e.g.
incomplete contact, short
circuit, defective battery
pack, etc.
LED red - continuous light
Battery temperature is out
side permissible limit values
(0 °C to 45 °C).
7 Settings
CAUTION
Risk of injury
► Only adjust the settings when the power
tool is switched off.
7.1 Changing direction of rotation [1-5]
• Switch to the left = clockwise rotation
•
Switch to the right = counterclockwise rota
tion
