Fetco CBS-2018 - Page 11

11
Parts List – Figure 1
ITEM # QTY PART NO DESCRIPTION
1 1 58064 ''READY'' GREEN LAMP 3/16 TERM. 120 VAC
2 1 58061 START ROCKER SWITCH N/O
3 1 58062 ''STOP'' ROCKER SWITCH
4 1 58063 ''POWER'' SWITCH ROCKER
5 1 58067 ''BREW'' INDICATOR LAMP 120 VAC, .187 TABS, .200 DIA. AMBER LENS
6 1 45076 OVERLAY, CBS-2018
7 10 82053 #6-32 X 1/2'' PHIL.TRUSS HD.MS.
8 1 002055 CONTROL PANEL COVER WELDMENT CBS-2018/18
9 1 001045 WELDMENT CBS-2018/18
10 1 71021 FAUCET, COMPLETE, HOT WATER, RED SAFETY HANDLE
10 1 71023 FAUCET UPPER ASSY., HOT WATER, RED SAFTEY HANDLE
10 1 71003 FAUCET SEAT CUP, HOT WATER
11 1 31075 HOT WATER FAUCET FITTING
14 1 101151 BREW BASKET ASSY. W/WIRE INSERT
15 1 03229 BOTTOM PLATE CBS-2018/18
16 1 23097 UNIVERSAL BASE CBS-2018/18
17 6 82034 #10 X 3/4'' HEX HD.SLOT SHEET METTAL SCREW
19 1 57058 S-53, 0.75 GPM VALVE, 120VAC
20 1 24012 S-53 FILL VALVE MOUNTING GASKET
21 1 31078 S-53 FILL VALVE INLET FITTING FOR S-53
22 1 03074 S-53 VALVE BRACKET
23 4 82020 SCREW FOR S-53
25 1 004036 WELDMENT TANK CBS-2018
26 2 83027 1/4'' S.S. INTERNAL TOOTH WASHER
27 2 84002 #8-32 S.S. HEX NUT
28 1 25084 1/4''ID. X 1/2'' OD. X 9.0" L. VENT SILICONE TUBE
29 1 25085 3/8'' ID. X 5/8'' OD.7.5"L. HOT WATER SILICONE TUBE
30 1 102080 SMALL SPRAY HEAD ASSEMBLY, 120VAC
31 4 84002 #8-32 S.S. HEX NUT
32 1 25086 1/2'' ID. X 3/4'' OD.X 3.5"L.BREW SILICONE TUBE
33 1 102172 DIGITAL TEMPERATURE PROBE
35 1 102013 TANK COVER ASSEMBLY
36 1 24002 TANK COVER GASKET
37 1 K031 ASSY. WATER LEVEL PROBE CBS-2018 (1.8L)
37 1 K030 ASSY. WATER LEVEL PROBE CBS-2018 (1.5L)
38 1 01398 COVER REAR CBS-2018/18
39 1 53071 SINGLE SHOT 230 F THERMOSTAT (TRIAC VER.)
40 4 84001 #6 -32 S.S. HEX NUT
41 1 401194 WIR.DIAGRAM CBS-2018 120 VAC, 1PH, 2 WIRE+GRD
41 1 401195 WIR. DIAGRAM CBS-2018 120/208-240 VAC, 1PH, 3 WIRE + GRD
42 2 22047 TANK INSULATION 1/2'' X 21 3/4'' X 7.0" CBS-2018/18
43 1 K023
CONTROL BOARD REPLACEMENT KIT, STANDARD SOFTWARE
(INCLUDES CONTROL BOARD AND #102172 DIGITAL TEMP PROBE ASSY)
44 10 29007 NYLON FINGER NUT, 4-40
45 1 31096 3/8MPT X 1/4' FLARE MALE 90 DEG. ELBOW
46 1 25087 COLD WATER SILICONE TUBE 3/8'' I.D. X 5/8'' O.D. X 12.5" L.
48 1 86007 HEYCO NYLON HOSE CLAMP DIA.593-.656
49 1 23099 STAND ZOJIRUSHI CBS-2018/18
50 1 03298 ONE SHOT THERMOSTAT SPACER
