15
Figure 4 – Brew Basket Assembly, 11 ¼” X 3 ¾”, Part # 101151
DWG 101151-003
ITEM QTY PART # DESCRIPTION
1 1 09018 WIRE INSERT, 11 ¼ ” X 3 ¾ ”
2 1 04064 BREW CONE
3 1 23074 BREW BASKET HANDLE, BLACK
4 2 82118 HANDLE SCREW
5
1 46011 WARNING LABEL
NOT
SHOWN
F007 PAPER FILTERS, 11 ¼ ” X 3 ¾ ”
500 PER CASE
COLOR BREW BASKET HANDLES
PART # DESCRIPTION
23169 BREW BASKET HANDLE, RED
23171 BREW BASKET HANDLE, GREEN
