2
Contact Information
FETCO®
Food Equipment Technologies Company
600 Rose Road
Lake Zurich • IL • 60047-0429 • USA
Internet: www.fetco.com
Phone: (800) 338-2699 (US & Canada)
(847) 719-3000
Fax: (847) 719-3001
Email: sales@fetco.com
techsupport@fetco.com
Description & Features
The CBS-2021eP brews directly into a 1.9L bowl server or our LUXUS® L3D-05 half-gallon thermal dispenser with
the stand removed.
The CBS-2021eG brews directly into our LUXUS® L3D-05 half-gallon thermal dispenser with the stand attached.
The CBS-2021 series features our patented intermittent spray over technology, which works as follows.
The following variables are programmed for each batch size:
Brew volume Prewet percent
Brew time Prewet delay
Bypass percent Drip delay
Using these variables, the software calculates how much water to use for prewetting, bypass and brewing. The
total brew time is divided into several 30-second cycles. Within these cycles, the software calculates how long to
spray water over the coffee grounds, and how long to pause before the next cycle begins.
Features
Two fully programmable batch sizes Cascading Spray Dome
Adjustable prewetting cycle Electronically controlled hot water service
Adjustable bypass Dual coffee filter sizes
Brew temperature protection
Specifications
Requirements
Water Requirements: Electrical: See electrical configuration chart.
Pressure: 20-75 psig
Minimum Flow Rate: ½ gpm
Coffee Filters: 11¼" X 3 ¾” Product # F007
or 9¾” X 4½” Product # F003
Weights and Capacities
Brewer / Dispenser Model
Brewer Weight
(empty)
Water tank
Capacity
Brewer Weight
(filled)
Dispenser
Weight (filled)
Total Weight
Brewer & Dispenser(filled)
CBS-2021eP / 1.9L Bowl 17.2 lbs. 1.6 gal. 30.0 lbs. 6.2 lbs. 36.2 lbs.
CBS-2021eP / L3D-05 16.5 lbs. 1.6 gal. 29.3 lbs. 7.4 lbs. 36.7 lbs.
CBS-2021eG / L3D-05 19.6 lbs. 2.5 gal. 39.9 lbs. 8.4 lbs. 48.3 lbs.
Electrical Configuration
Electrical Heater Voltage Maximum Batches
Config. Code Configuration (AC) Phase Wires KW Amp draw per Hour *
E20036 1 X 1.7 KW 120 single 2 + ground 1.7 14.6 6.5
E20016 1 X 2.1 KW 120 single 2 + ground 2.1 17.9 8.0
* Based on standard factory settings: 4.0 minute brew time; 0% prewet, 0% bypass; 201 F water.
