Fetco CBS-2042e - Contact Information; Description & Features; Features; Requirements

2
Contact Information
FETCO
®
Food Equipment Technologies Company
600 Rose Road
Lake Zurich • IL • 60047-0429 • USA
Internet: www.fetco.com
Phone: (800) 338-2699 (US & Canada)
(847) 719-3000
Fax: (847) 719-3001
Email: sales@fetco.com
techsupport@fetco.com
Description & Features
The CBS-2041e and CBS-2042e feature our patented intermittent spray over technology, which works like this:
The following variables are programmed for each batch size:
 Brew volume  Prewet percent (Percentage of the brew volume)
 Brew time  Prewet delay (The time between prewetting and the brew cycle.)
 Bypass percent
(Percentage of the brew volume)
 Drip delay (The time between the end of the brew cycle
and the unlocking of the brew basket.)
Using these variables, the software calculates how much water to use for prewetting, bypass, and brewing. The
total brew time is divided into several 30 second cycles. Within these cycles, the software calculates how long to
spray water over the coffee grounds, and how long to pause before the next cycle begins. The bypass valve opens
at the beginning of the brew cycle and dispenses the correct amount of water all at once.
Features
 Two fully programmable batch sizes per side  Magnetic brew basket sensor
 Adjustable prewetting cycle  Brew basket safety locks
 Adjustable bypass  Brew temperature protection
 Electronically controlled hot water service
Specifications
Requirements
 Water Requirements:  Electrical: See electrical configuration chart.
CBS-2041e: 20-75 psig, 1 gpm
CBS-2042e: 20-75 psig, 1 ½ gpm
 Coffee Filters: 13” X 5 ” FETCO Product # F002
Weights and Capacities
Brewer
Model
Weight
(empty)
Water tank
Capacity & Weight.
Weight
(filled)
Dispenser
Weight, ea.
Dispenser
Filled, ea..
Total Weight Brewer
& Dispensers, Filled
CBS-2041e 46 lbs. 4.2 gal. 35 lbs. 81 lbs. 8 lbs. 16 lbs. 97 lbs.
CBS-2042e 60 lbs. 7.4 gal. 61 lbs. 121 lbs. 8 lbs. 16 lbs. 153 lbs.
