Fetco GR-1.2 - Parts

10
Parts
Figure 1 – GR-1
Parts List – Figure 1 - GR-1
ITEM QTY PART.NO. DESCRIPTION
1 1 56002 MOTOR .67HP, 120VAC, 60HZ
1 1 56003 MOTOR .67HP, 220VAC, 50HZ (EXPORT VERSION ONLY)
2 4 84024 1/4''-20 HEX NUT 18-8 S.S.
3 4 83025 1/4'' S.S. SPRING LOCK WASHER
4 4 83034 1/4'' MILITARY S.S. WASHER
5 1 K056 COFFEE FLOW GUIDE (SET OF 2, ONE ON TOP OF THE OTHER)
