12
Figure 2 – GR-2
Parts List – Figure 2 - GR-2
ITEM QTY PART NO. DESCRIPTION
1 1 56002 MOTOR .67HP, 120VAC, 60HZ
1 1 56003 MOTOR .67HP, 220VAC, 50HZ (EXPORT VERSION ONLY)
2 4 84024 1/4''-20 HEX NUT18-8 S.S
3 4 83025 1/4'' S.S. SPRING LOCK WASHER
4 4 83034 1/4'' MILITARY S.S. FLAT WASHER
5 2 K056 COFFEE FLOW GUIDE (SET OF 2, ONE ON TOP OF THE OTHER)
6 1 23086 COFFEE OUTLET
7 2 82070 M3X8 PAN HD PHIL SCREW
8 1 03185 GRINDER MOTOR PLATE
9 2 97059 SINGLE COATED TAPE
10 4 82053 #6-32X1/2'' PHIL.SCREW TRUSS. HEAD M.S.
11 2 23085 MANIFOLD
