Fetco HWB-2 - Service and Support Details; Water Requirements and Capacity; Electrical Configuration; Unit Dimensions and Connection Points

2
Contact Information
FETCO Inc. Sp. z o.o.
ul. Adamowicza 8
05-530 Góra Kalwaria
Poland
Website: www.fetco.eu
Service & Support:
Hours: 8:00 AM - 4:00 PM Central, Monday - Friday
Phone: +48 22 727 47 87
Fax:
+48 22 727 47 87
Email: service@fetco.eu
Specifications
Water Requirements:
Weights and Capacity
)ytpme( .sbl 8.61 :thgieW gisp 57-02 :erusserP
Minimum Flow Rate: ½ gpm 33.4 lbs. (filled)
snollag 0.2 :yticapaC knaT
Electrical Configuration
Electrical Heater Voltage Maximum Hourly Heating
Config. Code Configuration (AC) Phase Wires KW Amp draw Capacity (gallons)
H02011 1 X 2.1 KW 120 single 2 + ground 2.2 18.0 5.4
Dimensions & Utility Connections
P- MAIN POWER SWITCH
E- ELECTRIC INPUT
D- DRAIN FITTING
W- WATER CONNECTION
8 5/8”
220 mm
17 7/8”
402 mm
21 1/4”
540 mm
8 7/8”
225 mm
5 1/2”
141 mm
4 3/4”
121 mm
