Page 25
Line Separator
Line voltage:
• Nominal DC 32 V (= V
nom
)
• Minimum DC 12 V (= V
min
)
• Maximum DC 33 V (= V
max
)
Switching current
(e.g., in the event of a short-circuit) Max. 2 A (= I
S max
)
Leakage current when switches are open Max. 1 mA (= I
L max
)
Serial impedance when switches are closed Max. 0.4 Ω (= Z
C max
)
The line separator is closed via an actuation signal from the control panel. Required line voltage: DC 12…33 V (normal range)
Voltage at which the line separator opens:
• Minimum DC 7.5 V (= V
SO min
)
• Maximum DC 10.5 V (= V
SO max
)
Permanent current when switches are closed Max. 1.5 A (= I
C max
)
