FG Wilson DCP-10 User Manual

DCP-10
Page 21/27
Datcon:
Murphy:
PT100:
Pre-set 1:
Pre-set 2:
Pre-set 3:
Pre-set 4:
Type 12：
：：
：
8.7 The optional items for configurable input:
Code Optional Function NOTE
0 not used
1 Pre-alarm (active immediately) low level is active
2 Shutdown Alarm(active immediately) low level is active
3 Pre-alarm (active after safety-on delay) low level is active
4 Shutdown Alarm(active after safety-on delay) low level is active
T(℃)
40 50 60 70 80 90 100 110 120 130 140
T(℉)
104 122 140 158 176 194 212 230
248 266 284
R(Ω)
900 600 400 278 200 141 104 74 50 27 4
T(℃) 40 50 60 70 80 90 100 110 120 130 140
T(℉)
104 122 140 158 176 194 212 230 248 266 284
R(Ω)
1029 680 460 321 227 164 120 89 74 52 40
T(℃)
-100
-50 0 20 40 60 80 100 150 200 300
T(℉)
-148
-58 32 68 104 140 176 212 302 392 572
R(Ω)
60 81 100 108 116 123 131 139 157 176 212
T(℃) 20 30 40 50 60 70 80 90 100 110 120
T(℉) 68 86 104 122 140 158 176 194 212 230 248
R(Ω)
900 600 420 282 152 113 86 62 48 40 30
T(℃) 30 50 60 70 80 90 100 110 120
T(℉) 86 122 140 158 176 194 212 230 248
R(Ω)
980 400 265 180 125 90 65 50 38
T(℃) 20 30 40 50 60 70 80 90 100 110 120
T(℉) 68 86 104 122 140 158 176 194 212 230 248
R(Ω)
805 540 380 260 175 118 83 58 42 30 21
T(℃) 28 35 40 50 60 70 80 90 95 98
T(℉) 82 95 104 122 140 158 176 194 203 208
R(Ω)
579 404 342 250 179 136 103 77 67 63
T(℃) 150 130 110 90 80 70 50 25 0 0
R(Ω) 6.9 10.8 17.7 30.6 41.1 56.3 111.8
300 964.4
964.4
