FUSES
Interior Fuses
• The interior fuse panel is part of the Body Control Module (BCM) and is located on
the driver's side under the instrument panel.
Cavity Vehicle Fuse
Number
Mini Fuse Description
1 F12 7.5 Amp Brown Right Low Beam
2 F32 5 Amp Tan
Front and Rear Ceiling Lights
Trunk and Door Courtesy
Lights
3 F53 5 Amp Tan Instrument Panel Node
4 F38 20 Amp Yellow Central Door Locking
5 F36 10 Amp Red
Diagnostic Socket, Car Radio,
Climate Control System
6 F43 20 Amp Yellow Bi-Directional Washer
7 F48 20 Amp Yellow Passenger Power Window
8 F13 7.5 Amp Brown
Left Low Beam, Headlamp Lev-
eling
9 F50 7.5 Amp Brown Airbag
10 F51 5 Amp Tan
Car Radio Switch, Climate Con-
trol System, Stop Light, Clutch
11 F37 5 Amp Tan
Stop Light Switch, Instrument
Panel Node
12 F49 5 Amp Tan
Exterior Mirror, GPS, Electric
Mirror, Parking Sensor
13 F31 5 Amp Tan Ignition, Climate Control
14 F47 20 Amp Yellow Driver Power Window
