Cavity
Vehicle Fuse
Number
Mini Fuse Description
13 F31 5 Amp Tan
Ignition, Climate Control, RDU
and EVCU
14 F47 20 Amp Yellow Driver Power Window
The fuse for the heated mirrors is located behind an access panel on the front of t he
Instrument Panel.
NOTE:
This fuse is a single fuse attached directly to the wire harness.
Cavity Mini Fuse Description
F90 5 Amp Tan Heated Mirrors
Power Distribution Center #1
The Power Distribution Center #1 is located on the right side of the underhood com-
partment. To access the fuses, remove locking screw and slide cover off.
The ID number of the electrical component corresponding to each fuse can be found on
thebackofthecover.
Cavity Maxi Fuse Mini Fuse Description
F01 60 Amp Blue – Body Control Module (BCM)
F02 20 Amp Yellow – Audio Amplifier
F03 20 Amp Yellow – Ignition Switch
F04 40 Amp Orange – Brake System Module Pump
F05 70 Amp Tan – Electric Power Steering (EPS)
F06 60 Amp Blue – Radiator Fan
F07 40 Amp Orange – Regen Brake Module
F08 40 Amp Orange – HVAC
F09 – 5 Amp Tan
Air Electric Heater
Charge Indicator
F10 – 10 Amp Red Horn
F11 – 10 Amp Red
Electronic Vehicle Control Unit
(EVCU)
F14 – 5 Amp Tan High Beam (Shutter)
F15 – 15 Amp Blue
Cigar Lighter, AUX Power Out-
let
F16 – 10 Amp Red
Humidity Sensor
VPAM
AC Compressor
F18 – 5 Amp Tan
Electronic Vehicle Control Unit
(EVCU)
F19 – 10 Amp Red HVAC
