114 STARTING AND OPERATING
The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following charts show the
warning alert operation when the system is detecting an obstacle:
WARNING ALERTS FOR REAR
Rear Distance
(inches/cm)
Greater than
59 inches
(150 cm)
59-52 inches
(150-130 cm)
52-41 inches
(130-105 cm)
41-34 inches
(105-85 cm)
34-24 inches
(85-60 cm)
24-12 inches
(60-30 cm)
Less than
12 inches
(30 cm)
Arcs — Left None None None None None 6th Flashing 5th Flashing
Arcs — Center None 10th Solid 9th Solid 8th Solid 7th Flashing 6th Flashing 5th Flashing
Arcs — Right None None None None None 6th Flashing 5th Flashing
Audible Alert
Chime
None
Single, 1/2
second, audible
chime is heard.
Audible chime increases as the object gets closer to the vehicle. Continuous
Radio Volume
Reduced
No Yes
WARNING ALERTS FOR FRONT
Front Distance
(inches/cm)
Greater than 39 inches
(100 cm)
39-32 inches
(100-80 cm)
32-24 inches
(80-60 cm)
24-12 inches
(60-30 cm)
Less than 12 inches
(30 cm)
Arcs — Left None None None 3rd Flashing 4th Flashing
Arcs — Center None 1st Solid 2nd Flashing 3rd Flashing 4th Flashing
Arcs — Right None None None 3rd Flashing 4th Flashing
