SERVICING AND MAINTENANCE 275
F11 – – 5 Amp Tan Supply Secondary Loads
F14 – – 15 Amp Blue Pump Power "After run" AGS Supply
F15 40 Amp Orange – – Brake Control Module Pump
F16 – – 5 Amp Tan Engine Control Module Power, Automatic Transmission
F17 – – 30 Amp Green Power Control Module Engine
F18 – – 30 Amp Green Power All-Wheel Drive
F19 – – 7.5 Amp Brown Air Conditioner Compressor
F20 – – 5 Amp Tan Electronic Power Four-Wheel Drive
F21 – – 15 Amp Blue Fuel Pump
F22 – – 10 Amp Red Supply Primary Loads
F23 – –
20 Amp Yellow
(Customer Installed)
Power Outlet (Battery Powered)
F24 – – 15 Amp Blue Electronic Unit Supply Automatic Transmission
F30 – – 30 Amp Green Heated Windshield – If Equipped
F83 – 40 Amp Green – Air Conditioning Fan
F84 – – 20 Amp Yellow Power Outlet (Ignition Powered)
F87 – – 5 Amp Tan Gear Selector Automatic Transmission
F88 – – 7.5 Amp Brown Heated Outside Mirrors
F89 – 30 Amp Pink – Heated Rear Window
F90 – – 5 Amp Tan IBS Sensor (Battery State of Charge)
Cavity Maxi Fuse Cartage Fuse Mini Fuse Description
8
21_FD_OM_EN_USC_t.book Page 275
