Fiat Capron A70 - Draining Water; Reducing the Water Quantity for Mobile Operation

110 Capron - 04-17 - CAP-0017-01EN
Sanitary fittings
11
11.2.4 Reducing the water quantity for mobile operation
Handle The handle is installed on the water tank.
Closing:
 Turn the handle (Fig. 99,1) on the water tank in a clockwise direction as far
as it will go.
 Fill the water tank with drinking water.
Opening:
 Turn the handle (Fig. 99,1) on the water tank in an anticlockwise direction
as far as it will go. Excess water will drain away leaving approx. 20 litres in
the tank.
11.2.5 Draining water
 Turn the handle (Fig. 100,1) on the water tank in an anticlockwise direction
as far as possible beyond the resistance to fully open the drainage
opening.
X When filling the water tank, observe the maximum permissible gross
weight of the vehicle. Luggage must be reduced accordingly when the
water tank is full.
Fig. 99 Water tank with handle
Fig. 100 Water tank with handle
