GROUP 1
Children from 9 kg to 18 kg in weight
can be carried facing forwards if the
child restraint system is fitted with
a front cushion, through which the
vehicle's seat belt restrains both child
and seat fig. 160.
114) 115)
GROUP 2
Children from 15 to 25 kg may use the
vehicle's seat belts directly fig. 161.
The child restraint system is now
needed only to position the child
correctly with respect to the belts so
that the diagonal section crosses the
child's chest and never the neck, and
the lower part is snug on the pelvis not
the abdomen.
114)
GROUP 3
For children from 22 kg to 36 kg in
weight the size of the child's chest no
longer requires a support to space
the child's back from the backrest.
The fig. 162 shows the correct child
positioning on the rear seat.
114)
Children over 1.50 m in height can wear
seat belts like adults.
160
F1A0152
161
F1A0153
162
F1A0154
165
