Right central pillar optional fuse box
fig. 232 - fig. 233
DEVICE PROTECTED FUSE AMPERE
Engine intake / ventilation fan (MBUS) F54 15
Heated
seats F55 15
Rear passenger power socket F56 15
Additional heater under the seat F57 10
Left heated rear window F58 15
Right heated rear window F59 15
Absent F60 –
Absent F61 –
Absent F62 –
Additional passenger heater control F63 10
Absent F64 –
Additional passenger heater fan F65 30
231
