PASSENGER
COMPARTMENT
VENTILATION
To ventilate the passenger
compartment well, proceed as follows:
❒ turn ring nut A to the blue section;
❒ stop internal air recirculation by
placing knob D on
;
❒ turn ring nut C to
;
❒ turn knob B to the required speed.
PASSENGER
COMPARTMENT HEATING
Proceed as follows:
❒ turn ring nut A to the red section;
❒ turn ring nut C to the required
position;
❒ turn knob B to the required speed.
FAST PASSENGER
COMPARTMENT HEATING
For the fast heating of the passenger
compartment, proceed as follows:
❒ turn ring nut A to the red section;
❒ start internal air recirculation by
placing knob D on
;
❒ turn ring nut C to
;
❒ turn knob B to 4
(max. fan
speed).
Then use the controls to maintain the
required comfort conditions and turn
knob D to
to turn the air
recirculation off and to prevent windows
from misting up.
IMPORTANT With a cold engine, you
have to wait for a few minutes to let the
system fluid reach optimum operating
temperature.
FRONT WINDOW FAST
DEMISTING/DEFROSTING
(WINDSCREEN AND SIDE
WINDOWS)
Proceed as follows:
❒ turn ring nut A to the red section;
❒ stop internal air recirculation by
placing knob D on
;
❒ turn ring nut C to
;
❒ turn knob B to 4
(max. fan
speed).
IMPORTANT To guarantee rapid
demisting/defrosting, if an additional
heater is present (under the front or rear
seat on Panorama and Combi
versions), if activated, deactivate it
using the F button (LED off) located in
the control panel fig. 47.
After demisting/defrosting, operate the
controls to restore the required comfort
conditions.
