FIBARO Dimmer 2 User Manual

2021. 04. 16.
https://manual.zwave.eu/backend/make.php?lang=en&sku=FIBEFGD-212
https://manual.zwave.eu/backend/make.php?lang=en&sku=FIBEFGD-212
13/14
Parameter 59: Approximated power at the maximum brightness level
This parameter determines the approximate value of the power thatwill be reported by the device at its maximum brightness level.0-500 (0-500W) - power
consumed by the loadat the maximum brightness level.
NOTE: Parameter 59 works only when parameter 58 has a value other than 0.
Size: 2 Byte, Default Value: 0
Setting Description
0 - 500 (0-500W) - power consumed by the load at the maximum brightness level.
Technical Data
Dimensions 42 x 38 x 20 mm
Weight 28 gr
Hardware Platform ZM5202
EAN 5902020528524
IP Class IP IP20
Voltage 100 -240V
Load 250 W
Device Type Light Dimmer Switch
Network Operation Always On Slave
Z-Wave Version 6.51.06
Certification ID ZC10-16045036
Z-Wave Product Id 0x010F.0x0102.0x1000
Frequency Europe - 868,4 Mhz
Maximum transmission power 5 mW
Supported Command Classes
Switch All
Application Status
Association Group Information
Association V2
Basic
Configuration
Crc 16 Encap
Device Reset Locally
Firmware Update Md V3
Manufacturer Specific V2
Meter V3
Multi Channel Association V3
Multi Channel V4
Notification V5
Powerlevel
Protection V2
Security
Sensor Multilevel V4
Switch Multilevel V3
Version V2
Zwaveplus Info V2
Controlled Command Classes
Basic

FIBARO Dimmer 2 Specifications

General

Wireless Protocol	Z-Wave
Dimming Range	0-100%
Protection Class	IP20
Maximum Load	250W (resistive load)
Operating Temperature	0°C to 35°C
Z-Wave Frequency	868.4 MHz (EU) / 908.4 MHz (US) / 921.4 MHz (ANZ)
Rated Load Current	1.1 A
Output Power	250 W (incandescent), 150 W (LED)
Range	Up to 50m outdoors
Dimensions	42.5 mm x 38.25 mm x 20.3 mm
