Fiber Options S711D - S711 F2 F Connection Pinouts and LED Key; S711 F2 F Data Connector J2 Pinout; S711 F2 F Power Connector Pinout; S711 F2 F LED Display Key

www.fiberoptions.com
Pin No. Function
8 Contact closure in, ground
7 Contact closure in
6 Contact closure out
5 Contact closure out
4 Ground
3 Not connected
2 Ground
1 Data In/out
Pin No. Function
3 +13 to 16 VDC
2 Not connected
1 Ground
LED Name Signal Color Indications
Green
Any shade of green indicates
adequate optical signal
LEVEL/
LOSS
Optical
Red Optical loss exceeds budget, or no
Off No activity on copper at either end
Green
Receiving data over fiber (steady or
pulsing)
DATA
IN
F2F I/O
Amber
Transmitting data over fiber (steady or
pulsing)
Green
Contact closure IN (pin 7) shorted to
ground
DATA
OUT
Contact
Closure IN
Amber
Contact closure IN (pin 7) open (not
shorted to ground
Green
Receiving a CLOSED command from
the fiber
ENABLED
Contact
Closure OUT
Red
Receiving an OPEN command from
the fiber. *
*If the LEVEL/LOSS LED is red, this LED will be red and the contacts will be open. If the unit is
powered down, the contacts open.
Table 1
Pin Connections for Data Connector J2
Table 2
Pin Connections for Power Connecto
r
Table 3
LED Display Key
