S711D & S7711D - STANDALONE MODULES - 10-PIN DATA CONNECTION TABLES
nc = no connection
Pin No.
Function
10 Ground
9 nc
8 nc
7 RS232 IN
6 nc
5 nc
4 RS232 OUT
3 Ground/Shield
2 Ground
1 +12 VDC
2 Ground
1 +12 VDC
2 Ground
2 Ground
2 Ground
2 Ground
1 +12 VDC
1 +12 VDC
2 Ground
1 +12 VDC
2 Ground
1 +12 VDC
2 Ground
1 +12 VDC
1 +12 VDC
1 +12 VDC
Data Select switch: Position 1
RS232 Interface
Pin No. Function
10 Ground
9 nc
8 RTS/CTS IN
7 RS232 IN
6 nc
5 RTS/CTS OUT
4 RS232 OUT
3 Ground/Shield
Data Select switch: Position 2
RS232 with Handshaking Interface
Pin No. Function
10 Ground
9 nc
8 TTL IN
7 tie to pin 3
6 nc
5 TTL OUT
4 nc
3 Ground/Shield
Data Select switch: Position 3
TTL Interface
Pin No.
Function
10 Ground
9 nc
8 RS422 IN +
7 RS422 IN -
6 nc
5 RS422 OUT +
4 RS422 OUT -
3 Ground/Shield
Data Select switch: Position 4
RS422 Interface
Pin No.
Function
10 Ground
9 RS485 termination - tie to pin 5
8 RS485+
7 RS485 -
6 +5 VDC BIAS OUT
5 nc
4 nc
3 Ground/Shield
Position 8 = 2V offset
Data Select switch:
RS485 2-Wire Interface
Position 7 = 1V offset
Position 6 = standard offset
Pin No.
Function
10 Ground
9 RS485 termination - tie to pin 5
8 RS485 in +
7 RS485 in -
6 +5 VDC BIAS OUT
5 RS485 out +
4 RS485 out -
3 Ground/Shield
Position B = 2V offset
Data Select switch:
RS485 4-Wire Interface
Position A = 1V offset
Position 9 = standard offset
Pin No.
Function
10 Ground
9 nc
8 Manchester/Biphase in +
5 nc
7 Manchester/Biphase in -
6 nc
4 Manchester/Biphase out +
3 Manchester/Biphase out -
Data Select switch: Position 5
Manchester/Biphase Interface
Pin No.
Function
10 Ground
8 Manchester/Biphase in +
5 nc
7 Manchester/Biphase in -
6 nc
4 Manchester/Biphase out +
3 Manchester/Biphase out -
9
Manchester/Biphase
termination
tie to pin 7
Data Select switch: Position 5
Manchester/Biphase Interface
Termination Unit
Pin No.
Function
10 Ground
9 nc
8 tie to pin 5
7 tie to pin 4
6 nc
5 tie to pin 8
4 tie to pin 7
3 nc
Data Select switch: Position F
Test Mode Loopback Interface
TABLE 10: TABLE 11: TABLE 12:
TABLE13:
TABLE 18:
TABLE 17:
TABLE 16:
TABLE 14:
TABLE 15:
S711D & S7711D Instruction Manual
